SM200 metal stress detector

 SM200 metal stress detector

Main technical parameters:

1. Host measurement points: 16 points (stress-strain measurement); 5 points (residual stress measurement)

2. Measurement units: μ ε, kN, mm, MP

3. Measurement range: strain 0~± 38000 μ ε; Displacement ± 1.0000~± 99999mm;

    Residual stress: ± 60000MP tensile pressure ± 1.0000~± 99999kN

4. Balance range: ± 38000 μ ε

5. Resolution: Strain: 1 μ ε; Tensile force and displacement: 0.01%/F.S; Residual stress: 0.01mpa

6. Balance method: automatic scanning balance

7. Scanning speed: 16 channels/0.5 seconds

8. Sensitivity setting range: 1.000-9.999 (single point setting, unified setting)

9. Bridge supply voltage: DC 2V

10. Automatically detect and calculate residual principal stresses and angles (σ 1, σ 2, θ), and print and store them online or offline

11. Applicable bridge resistance: 60~1K Ω

12. Display window: 1

13. Display mode: LCD display

14. Operation method: Touch screen operation

15. Bridge grouping methods: 1/4 bridge, half bridge, full bridge, hybrid bridge grouping, 1/4 bridge single ended compensation bridge connection method.

16. Zero drift: ± 3 μ ε/4 hours; ±1με/℃

17. Accuracy: 0.5%

18. Nonlinear: ± 0.02% F.S

19. Measurement function: data storage, data playback

20. Data storage capacity: 1000 pages (16 channel data/page)

21. Working mode: Local self-control/Computer external control

22. Computer interface: USB 2.0

23. Temperature: -10 to+45 ℃

24. Power supply: AC220V 50Hz

25.Most advanced precision
